ECOSPIR A/ID
A PALLET STRETCH
WRAPPER FOR ALL APPLICATIONS
|
| SPECIFICATIONS |
ECOSPIR
ELC
|
| Power supply |
380 V - 3 Ph - 50
Hz |
| Power
required |
0,8
KW |
| Overall machine dimensions
DIA x L x H |
1500 x 2440 x 2550
mm |
| Turn-table
height above floor |
70
mm |
| Weight |
430 kg |
| Turn-table
dimensions |
1500
mm |
| Maximum pallet dimensions |
1200 x 1200 mm |
| Maximum
pallet height |
2200
mm |
| Maximum pallet weight |
1800 kg |
| Maximum
roll diameter |
300
mm |
| Roll height |
500 mm |
| Compressed
air |
80
Nl - 6 bar |
| Turn-table speed |
Up to 10 cycle/min |
|
